Bill of Materials

Quantity - Size - Material - Style

4 - 69" lumber 1x2
2 - 2.5" lumber 1x2
2 - 6 7/8" lumber 1x2
2 - 3.5" lumber 1x2
4 - 24" lumber 1x4
2 - 6 11/16" lumber 1x4
1 - 16" lumber 1x4
1 - 16 13/16" lumber 1x4
1 - 15.5" lumber 1x4
2 - 18" lumber 1x4
4 - 24" lumber 1x1 (exact measurements)
30' - wire 2-conductor #24 stranded
8' - wire 2-conductor #14 stranded
2 - 4" " bolts round head
1 - 22" 10-24 bolts round head
3 - 2.5" " bolts round head
1 - 5" " bolts round head
2 - 3" 1/8" bolts round head
36 - 1.5" 1/8" screws Phillips
3 - 3mm lamps 14-volt
1 - 10-tooth sprocket " shaft
1 - 40-tooth sprocket " shaft
1 - 2900-rpm motor 1-amp, 115-volt Oriental Motor Co., Ltd.
1 - 1:11 gearbox Oriental Motor Co., Ltd.
1 - 26" sprocket chain like bicycle chain
1 - 3" turnbuckle
1 - 6"x1/8" flat bar
12 - small plastic wire clips
2 - 6" bare wire #16
4 - " eye screws " O.D.
3 - 14"x4" 1/16" acrylic sheets
10' - string cotton
3 - 1"eye screws " O.D.
3 - 1.5"corner brackets
2 - 1" pulley wheels
4 - small metal pulleys enclosed
1 - small double pulley enclosed
2 - 8"x" metal strapping perforated, galvanized
1 - 15" N-scale track Atlas
1 - 1.5"x1"x2" foam rubber for bumper in elevator
1 - DT-4 Circuitron
3 - Opto-Sensors Circuitron
2 - 1/8" I.D. rubber grommets
1 - 1.5" bearing on 3" extender rod
3 - 1/8" I.D. brass eyelets, SIG, part SH-215
1 - 4"x2.5" shelf bracket
2 - 5" corner brackets
1 - "x8" shaft
14 - 3/8" I.D. washers
2 - 1" corner bracket
1 - 1"x1" rubber roller on " shaft, for sanding cylinders
1 - 5"x1/4" eyebolt
2 - " wingnuts
1 - 2" nuts
1 - DPDT GC miniature bat handle toggle switch
1 - 3" 10-24 bolt round head
1 - 5"spring-loaded curtain pulley assembly (cord tension pulley)
